Turmeric Grinding Machine

Product Description

To avail our clients one of the most exclusive and productive units for industrial turmeric grinding purposes on a bulk parameter, we have brought forth to our clients one of the most efficient and exclusive kinds of Automatic Turmeric Grinding Machines. These automatic turmeric grinding plants have been excellently designed and fabricated which makes it highly useful and effective in grinding raw turmeric to make turmeric powders which is used for cooking purposes. We are not only manufacturing but also are supplying and exporting these top grade automatic turmeric grinding plants. With growing population, changing food habits and increase in disposable incomes, the demand is steadily growing. At the same time, there are some regional and national producers who have established their names and brands especially in urban markets. Hence, a new small scale unit with limited financial resources has to concentrate on semi-urban and rural markets where these brands are not much popular, price is the driving factor and consumers prefer fresh spices. Marketing will be a key success determinant in this line.

Manufacturing process:-

To start with, unground turmeric are cleaned manually to remove impurities. Turmeric's are pulverized in a grinder to convert them in powder form. Turmeric being solid by nature, it is taken to disintegrator and then pulverized. Then spices in powder form are passed through sieves to obtain uniform mesh size. Finally, packing is done in polythene bags and bags are sealed. Process loss is in the range of 5% to 7%.

Operating principle of Turmeric grinding machine:-

The Turmeric grinding machine consists of an encased rotor carrying swing hammers, whizzer classifier for fineness regulation and pressure gradient creator mounted on a solid shaft. Raw material to be pulverized enters the crushing chamber through the hopper or the automatic rotary feeder. The impact of the hammers on the feed material against the liner plates reduces it into fine powder. The ground material is carried towards the whizzer classifier for classification and the oversize particles are rejected by the classifier and returned to the crushing chamber for further grinding. The classified material is then conveyed into the cyclone for collection and bagging. A dust collector is provided in the system for ensuring dust less operation and for no loss of ground powder.

Specification
